HV-C/CP and HW-C/CP Multi-Functional Platform Scales
High performance, multi-functional platform scale for standard industrial applications. Improve efficiency in your weighing process with fast stabilisation times and built-in LED lights for quick comparator judgments. Various capacities to select from in the HW-C range, as well as triple range capacities with the HV-C models.
Related Video
HV-C/CP and HW-C/CP Multi-Functional Platform Scales
Features
- NMI Trade Approval for HV-C & HV-CP models
- High-speed measurement—stabilization within 1 second (for the HV-C/CP series)*1*2
- Bright and multi-colored 5-step LED comparator lights
- Auto-tare and negative comparison functions realizing “take-away” check weighing
- Highly-visible, LCD display (26 mm character height) with white backlight
- Quick and easy settings using the alphanumeric keypad
- Key lock function to prevent operators from making changes to the scale settings
- Optional roller conveyers for weighing in production lines
- Built-in (thermal) printer for creating paper-based records on the spot (for the HV/W-CP series)
- Universal Flexi Coms (UFC) function to edit serial data output/printout format
- Wide selection of capacities and readabilities
- IP65 dust & waterproof base unit with a stainless steel (SUS430) pan
- Three slots for optional data communication interfaces
- Display hold function
- Counting mode function
- Accumulation (M+) function
- Operation with either AC adapter or four D batteries (for the HV/W-C series)*3
- Display angle adjustable to four levels
- Optional 5 m extension cable and wall-mount bracket for the display unit
- Display cover provided as standard
Model & Capacity(scroll right for purchase/enquiry details)
| Model | Capacity | Weighing Pan | Unit Price excluding GST |
Action |
|---|---|---|---|---|
| HV-15KC Triple Range |
3kg x 1g
6kg x 2g
15kg x 5g
|
250mm x 250mm | $1200.00 |
 Enquire
|
| HV-15KC Triple Range (Trade Approved Version) Verification can take up to 5 business days |
3kg x 1g
6kg x 2g
15kg x 5g
|
250mm x 250mm | $1290.00 |
Enquire
|
| HV-60KC Triple Range |
15kg x 5g
30kg x 10g
60kg x 20g
|
340mm x 424mm | $1300.00 |
Enquire
|
| HV-60KC Triple Range (Trade Approved Version) Verification can take up to 5 business days |
15kg x 5g
30kg x 10g
60kg x 20g
|
340mm x 424mm | $1315.00 |
Enquire
|
| HV-200KC Triple Range |
60kg x 20g
150kg x 50g
200kg x 100g
|
390mm x 530mm | $1485.00 |
Enquire
|
| HV-200KC Triple Range (Trade Approved Version) Verification can take up to 5 business days |
60kg x 20g
150kg x 50g
200kg x 100g
|
390mm x 530mm | $1585.00 |
Enquire
|
| HV-15KCP Triple Range Printer |
3kg x 1g
6kg x 2g
15kg x 5g
|
250mm x 250mm | $1465.00 |
Enquire
|
| HV-15KCP Triple Range Printer (Trade Approved Version) Verification can take up to 5 business days |
3kg x 1g
6kg x 2g
15kg x 5g
|
250mm x 250mm | $1555.00 |
Enquire
|
| HV-60KCP Triple Range Printer |
15kg x 5g
30kg x 10g
60kg x 20g
|
340mm x 424mm | $1560.00 |
Enquire
|
| HV-60KCP Triple Range Printer (Trade Approved Version) Verification can take up to 5 business days |
15kg x 5g
30kg x 10g
60kg x 20g
|
340mm x 424mm | $1660.00 |
Enquire
|
| HV-200KCP Triple Range Printer |
60kg x 20g
150kg x 50g
200kg x 100g
|
390mm x 530mm | $1750.00 |
Enquire
|
| HV-200KCP Triple Range Printer (Trade Approved Version) Verification can take up to 5 business days |
60kg x 20g
150kg x 50g
200kg x 100g
|
390mm x 530mm | $1850.00 |
Enquire
|
| HW-10KC without Printer |
10kg x 1g
|
250mm x 250mm | $1090.00 |
Enquire
|
| HW-60KC without Printer |
60kg x 5g
|
330mm x 424mm | $1195.00 |
Enquire
|
| HW-200KC without Printer |
200kg x 20g
|
390mm x 530mm | $1365.00 |
Enquire
|
| HW-10KCP Integrated Printer |
10kg x 1g
|
250mm x 250mm | $1340.00 |
Enquire
|
| HW-60KCP Integrated Printer |
60kg x 5g
|
330mm x 424mm | $1440.00 |
Enquire
|
| HW-200KCP Integrated Printer |
200kg x 20g
|
390mm x 530mm | $1625.00 |
Enquire
|
-
-
Where can I purchase this equipment?
A&D Australiasia has a nation wide dealer network with outlets in all capital cities and in most regional locations. Call Toll Free 1800 241 434 for the location of your nearest dealer.
My product requires service/repair, how do I arrange this?
Contact the A&D Australiasia Service department on 08 8301 8120 or at [email protected] and they can advise on and coordinate your service requirement.
-
All A&D products purchased within Australia are covered by a warranty period which varies from 12 months to 5 years depending on the model.
Warranty covers against any defects in the material and workmanship negligence during the manufacture or assembly of the product for the period of the warranty.
Warranty claims should be submitted through your initial dealer or place of purchase with your proof of purchase tax invoice.
